Outlook

Feature

  • Support Freescale i.MX6 Dual/Quad Processor
  • eMMC NAND Flash 4GB on board
  • DDR3 800MHz on board optional 1GB
  • LVDS x 2CH, HDMI(1920x1080) x 1
  • Giga LAN x 1
  • SATA x 1, SDIO x 1
  • SPI , CAN , I2S , I2C , UART
  • PCIe x 1
  • GPIO x 8
  • USB OTG x 1, USB HOST x 1
  • Micro SD Card Slot x 1
  • Target Applications: Automotive applications, HMI, Industrial areas

Module Board Dimensions

i.MX6 Q7 Specification

  • Main

  • Processor Freescale ARM Cortex A9™ core i.MX6 Dual / Quad 1GHz
    Memory DDR3 800MHz 1GB
    eMMC NAND Flash 4GB
  • I/O

  • Gold Finger QSeven™ Specification 2.0, Detail as gold finger specification.
    Micro SD Socket Support Micro SD
    TTL Connector RGB24bits (FPC Connector 30pin)
    3-asix Accelerometer Freescale MMA8451Q
  • Environment

  • Operating Temperature - 40°C ~ 85°C
    Humidity 10% - 85% Non-condensing
  • Dimension

  • Form Factor QSeven™ Specification Rev 2.0 Compatible (70 X 70 mm)
  • Gold Finger

  • Display LVDS
    HDMI
    LVDS X 2 CH
    HDMI(1920x1080) X1
    Storage SATA
    SDIO
    X1
    X1
    I/O Bus SPI, CAN, I2S / AC97, I2C, JTAG, UART
    PCIe X1 lane
    USB OTG
    Host
    X1
    X1
    LAN 10M/100M/1Gigabit X1
    Status Signal Thermal Control, Fan Control
    Buttons Power Button, Reset Button, Sleep Button Home Button, Return Button, Volume Up Button, Volume Down Button
    Power 5Vcc
    STB 5V
    VCC_RTC
    DC5V 2A
    Support MCU Power
    Support MCU Sleep Power
  • OS

  • Android 4.2 or above
    Ubuntu 12.04 (Under Development)
    Linux Embedded Linux 3.6.35
  • SW Customization

  • AP Customization is possible
    API Customization is possible
    Kernel Customization is possible
    Driver Customization is possible

Accessory

  • Customized Carrier Board service is available on request (ODM / OEM).
  • Provide Retronix's Evolution Board for design verify (Industrial grade, Unit price USD 100).
