Outlook

Dimensions

Feature

  • iSMART - for EuP/ErP power saving, auto-scheduler and power resume
  • Intel® Atom™ Processor E3845 SoC (22nm); Quad-Core @ 1.91GHz
  • Intel® HD Graphics (Gen 7-LP) 4EU
  • 2x DDR3L-1333 SO-DIMM, dual channel, Max. 8GB
  • Supports 2x HDMI
  • 1x Mini PCI-E(x1) slots for WiFi + Bluetooth, 3G, and TV tuner board options
  • Fanless, super slim and compact design
  • Wide operating temperature from -30°C to 60°C

Specification

  •

  • System Mainboard IB812
    CPU Type Intel® Atom™ E3845 SoC (22nm); Quad-Core @1.91GHz Integrated Graphics Core
    CPU Socket FCBGA 1170 BGA -- aka Atom “Type 3” (25mm x 27mm)
    Chipset SoC Integrated
    Memory 2x DDR3L-1333 SO-DIMMs, Dual Channel, Max. 8GB (Non-ECC)
    Graphics Intel® HD graphics (Gen 7-LP) 4EU
    LAN 1x RJ-45 GbE (Realtek RTL8111G-CG)
    Expansion Slots 1x mPCIe(x1) for WiFi + Bluetooth, 3G, and TV tuner options
    1x UIM/SIM card slot (for 3G/LTE adaptor in mPCIe slot)
    I/O Interface 2x HDMI
    1x USB 3.0 port, 2x USB 2.0 ports
    1x RJ45 for LAN, 1x RJ45 for RS232
    2x audio connectors for Line-in / Line-out
    Power / HDD LED, 1x power on/off button
    1x DC jack
    Auto Control and Monitoring Watchdog Timer: 256 segments, 0, 1, 2…255 sec/min
    Power Requirement +12V DC-in
    Construction Aluminum + SGCC
    Weight 0.8Kg (1.76lbs)
    Chassis Color Black & white
    Storage 1x mSATA
    Power Supply 60W power adaptor
    Mounting Standard system bracket
    Dimensions 190mm(W) x 130mm(D) x 19.5mm(H)
    7.48”(W) x 5.12”(D) x 0.77”(H)
    Operating Temperature -30°C ~ 60°C (-22°F~140°F)
    Storage Temperature -40°C ~ 80°C (-40°F~176°F)
    Relative Humidity 5~90% @ 45°C, (non-condensing)
    Vibration mSATA: 5 grms / 5~500Hz / random operation
    Certification CE/FCC, VCCI class B, UL & CCC
    OS Information Ubuntu 12.04

Ordering Information

  •

  • SI-12 Signage Player with Intel® Atom™ E3845 SoC (22nm);
    Quad-Core @ 1.91 GHz, 4GB SO-DIMM RAM,
    64GB mSATA, and 60W power adaptor
    SI-12M Signage Player with Intel® Atom™ E3845 SoC (22nm);
    Quad-Core @ 1.91 GHz, w/o memory, mSATA,
    with 60W power adaptor
    SI-MK1 Mounting bracket for SI-06/08/12/18/22 series
